Features
Support JEDEC/ e•MMC 5.1 Compliant
Support 3.3V/1.8V power supply
Support 12 wire bus (CLK, CMD, Data Strobe, DAT[7:0] and hardware reset (RST_n))
Up to 200MHz clock speed
Support Single Data Rate(SDR) and Dual Data Rate(DDR)
Support different Bus width:1bit, 4bit, 8bit
Support Original Boot and Alternative Boot modes
Support Data Removal (Erase, Trim and Sanitize)
Support Replay Protected Memory Block(RPMB)
Support Multiple Partitions with enhanced attribute
Support Lock/Unlock and Write Protection
Support Data Protection for Power Failure
Support Power Saving Sleep Mode
Support High Priority Interrupt(HPI)
Support Background Operation
Support Packed Commands
Support Sampling Tuning Sequence
Support Dynamic Power Manager : standby and sleep modes
Support Command Queuing
Support Secure Write Protection
Package size
- 11.5mm x 13.0mm x 1.0mm
- 11.5mm x 13.0mm x 1.16mm
Operating Voltage range
- VCC = 2.7V~3.6V (typical 3.3V)
- VCCQ = 1.7V~1.95V(typical 1.8V), 2.7V~3.6V (typical 3.3V)
Temperature
- Operating : -40℃ ~ 85℃
- Storage : -45℃ ~ 105℃
Program/Erase Cycle
- >= 3000
